SAF500 is a standard duty plummer blocks series for split or pedestal housing support for shafts requiring serviceable bearing-housing arrangements. The page keeps the complete catalogue drawing and model-by-model dimensional reference together for RFQ selection.
MOQ: 50 pcs. Minimum order value USD 1,500; mixed orders and trial quantities welcome.
SAF500 is a standard duty series configured around plummer blocks. Its catalogue definition uses see catalogue drawing/table, with individual bore and dimensional variants retained in one model table.
The page keeps the full series together because housing geometry and locking method define the product family more clearly than a single bore size. Exact unit numbers remain in the source table for side-by-side checking.
The series can also be compared with other mounted-bearing families when the machine design is still open. Start from the bearing index, then return to the drawing that best matches the mounting interface. Browse related bearing families.
SAF500 is treated as one catalogue series, with individual unit numbers retained inside the dimensional table.
The primary configuration is plummer blocks, intended for split or pedestal housing support for shafts requiring serviceable bearing-housing arrangements.
The catalogue identifies see catalogue drawing/table for this series; confirm the exact row before ordering.
Use these identifiers as the first selection gate. They capture the catalogue family, duty, locking and mounting form, while the numerical model rows remain grouped in the source table below.
| Series | SAF500 |
|---|---|
| Catalogue Reference | Part B, page B64 |
| Product Family | Plummer Blocks |
| Duty Classification | Standard duty |
| Locking / Mounting Method | See catalogue drawing/table |
| Inner Ring / Bore Form | Wider inner ring / series-specific bore |
| Housing / Configuration | Plummer Blocks |
| Material Note | Material varies by unit; confirm selected model |
When replacing an installed unit, use the outline drawing as a dimensional fingerprint. Match the fixed machine dimensions before relying on a partially legible model code or a visually similar housing.
SAF500 is relevant when belt drives and fans requires this housing format; verify shaft geometry, mounting interface, operating conditions and environment before final selection.
For process equipment, this series provides the catalogue mounting form shown above. Confirm load, speed, shaft dimensions and service environment for the chosen model.
SAF500 is relevant when industrial shafts requiring accessible housing service requires this housing format; verify shaft geometry, mounting interface, operating conditions and environment before final selection.
Below is the full dimensional reference for this series rather than a shortened web transcription. Keeping the table intact reduces the risk of separating a dimension from the wrong bore or unit suffix.
Begin with the machine mounting envelope, then confirm the shaft and locking arrangement. A similar series code does not guarantee the same center height, bolt pattern, cartridge fit, slot geometry or inner-ring dimensions. In this family, the intended role is split or pedestal housing support for shafts requiring serviceable bearing-housing arrangements.
| Step | Information To Confirm |
|---|---|
| 1 | shaft diameter and bearing designation |
| 2 | housing series and center height |
| 3 | seal arrangement |
| 4 | fixed/floating requirement and lubrication method |
A practical selection review starts with geometry and locking method, then verifies the exact model row. Special coatings, covers, grease, seals or material options should only be treated as included when they are stated for the chosen configuration.
For a faster series check, include the installed unit code when available, plus shaft size, quantity and a photo or drawing of the mounting interface. Ever Power Netherlands Branch can review the quotation basis against the same reference.
