GE C Spherical Plain Bearing is a documented maintenance-free series for industrial linkage or pivot applications. Maintenance-free PTFE composite sliding layer; outer ring pressed around the inner ring. Use the main image for identification and the full product description for model-by-model dimensions and load data.
MOQ: 50 pcs. Minimum order value USD 1,500; mixed orders and trial quantities welcome.
GE C is a compact maintenance-free radial spherical plain bearing. The outer ring is pressed around the inner ring and carries a PTFE composite sliding layer, while the spherical surface of the inner ring is chromium plated. The catalogue covers 6–30 mm bores.
| Model | Bore d (mm) | Outside D (mm) | B (mm) | C (mm) | Tilt α (°) | Dynamic Load (kN) | Static Load (kN) | Weight (g) |
|---|---|---|---|---|---|---|---|---|
| GE6C | 6 | 14 | 6 | 4 | 13 | 3.6 | 9.1 | 4 |
| GE8C | 8 | 16 | 8 | 5 | 15 | 5.8 | 14 | 8 |
| GE10C | 10 | 19 | 9 | 6 | 12 | 8.6 | 21 | 11 |
| GE12C | 12 | 22 | 10 | 7 | 10 | 11 | 28 | 15 |
| GE15C | 15 | 26 | 12 | 9 | 8 | 18 | 45 | 27 |
| GE17C | 17 | 30 | 14 | 10 | 10 | 22 | 56 | 41 |
| GE20C | 20 | 35 | 16 | 12 | 9 | 31 | 78 | 66 |
| GE25C | 25 | 42 | 20 | 16 | 7 | 51 | 127 | 119 |
| GE30C | 30 | 47 | 22 | 18 | 6 | 65 | 166 | 163 |
This family is attractive where a grease line would complicate a compact assembly. Select by d, D, B and C first, then check the catalogue load ratings and tilt angle.
Do not add a grease routine to a PTFE maintenance-free bearing unless a project-specific engineering instruction explicitly calls for it.
GEG C provides a heavier maintenance-free envelope; GE E / GE ES 2RS is serviceable and available across a much broader bore range; GE ET 2RS uses PTFE fabric and double seals.
