LIN-01RK lin-01rk split/open-style series from the LIN plastic linear-bearing family. Designed for quiet, corrosion-resistant dry running; exact dimensions and load data remain model specific.
LIN-01RK has its own open-style catalogue geometry and should be matched to the support and housing dimensions shown for this suffix. The RK geometry is best handled as its own replacement family. Matching only the bore can overlook the split profile and housing details shown in the catalogue.
This polymer family trades rolling elements for a dry sliding surface. The catalogue records 1.48 g/cm³ density and a dry friction coefficient against steel between 0.05 and 0.15. The source separates steady and short-term temperatures: -50…+90 °C continuous, with short excursions permitted to +120 °C.
| Check | Source Data | Engineering Use |
|---|---|---|
| Key drawing fields | order code / d1 / open geometry / d2 / B / housing fit / C / Co / weight | Read the exact model row |
| Dry sliding coefficient | 0.05–0.15 against steel | Family material value |
| PV ceiling | 0.4 N/mm²·m/s | Combined pressure-speed limit |
| Material density | 1.48 g/cm³ | Published LIN material property |
| Temperature window | -50/+90 °C continuous; to +120 °C short | Check ambient and frictional heating |
| Source pages | 82–102 | Supplied linear-bearing catalogue |
| Series / form | LIN-01RK | LIN-01RK split/open-style series |
Data boundary: The figures above are published family properties. Exact dimensions, housing fits and load values for LIN-01RK stay model specific and should come from the selected catalogue row.
RK variants are best suited to equipment already designed around that split profile. They can serve dry-running guides in automation and handling devices where lubricant migration is undesirable.
For LIN-01RK, corrosion resistance and lubricant-free travel can simplify machine housekeeping. The catalogue also notes that the LIN material can be cleaned with disinfecting solution, which is useful context for equipment where oil migration would be undesirable.
For RK, compare the actual split profile, housing fit and length against the catalogue image. The shaft diameter is only one of several identification points.
After the geometry is identified, compare the real duty with the dry-running material limits. Record load, sliding speed, stroke, shaft finish and operating temperature in the RFQ so LIN-01RK is checked as a system rather than as a bore-size lookup.
Keep the split geometry aligned with its mating support and prevent fasteners or housing clamps from closing the bearing beyond the intended fit.
This family does not depend on scheduled grease replenishment. Inspection should instead look for abnormal clearance, embedded abrasive particles, heat and uneven wear; those symptoms often point to shaft or alignment issues around the LIN-01RK installation.
Send the LIN-01RK model if known, shaft size, quantity, mounting dimensions and duty conditions to sales@netherlandsdrive.com. Ever Power Netherlands Branch will use the supplied catalogue family as the technical reference for selection.
